Hydraulic Motor BMS Series With 180° Apart Ports Equivalent To OMS MS

Brand Name : HANJIU

Model Number : BMSY-100-E2B-G-EE-S2

Certification : CE, ISO9001

Place of Origin : China

MOQ : 100 Pieces

Price : 88 usd/pc

Payment Terms : T/T

Supply Ability : 70000 pieces per year

Delivery Time : 0 - 35 work days

Packaging Details : Box, carton, pallet

Product : Hydraulic Motor

Model No. : BMSY-100-E2B-G-EE-S2

Displacement : 100cc

Flange : 2 bolt

Shaft : 32mm

Port : G 1/2

Rotation : Standard

Color : Black

Manufacturer : Hanjiu

Brand : Hanjiu

Contact Now

Hydraulic motor BMS series with 180° Apart ports Equivalent to OMS MS​

Quick review:

Model No. BMSY-100-E2B-G-EE-S2
Geometric displacement 100 cm³
Max. speed continuous. 748 rpm
Max. speed intermittent. 900 rpm
Max. torque continuous. 290 Nm
Max. torque intermittent 390 Nm
Max. pressure continuous 210 bar
Max. pressure intermittent. 250 bar
Max. pressure peak 270 bar

BMS series with more mounting and shaft apply to Swing Motor, Brush Cutters & Mowers, Harvesting Equipment, Directional Boring any place pressure relief protection is optimal for system or motor performance and life, Turf equipment and more.

Specification:

Main Specifications:
Type BMS
BMSE
80		 BMS
BMSE
100		 BMS
BMSE
125		 BMS
BMSE
160		 BMS
BMSE
200		 BMS
BMSE
250		 BMS
BMSE
315		 BMS
BMSE
375
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque (N·m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

Dimentions:

Hydraulic Motor BMS Series With 180° Apart Ports Equivalent To OMS MS

More BMS series hydraulic motors available from us:

Hydraulic Motor BMS Series With 180° Apart Ports Equivalent To OMS MS

More hydraulic motors available:

Hydraulic Motor BMS Series With 180° Apart Ports Equivalent To OMS MS

Hydraulic Motor BMS Series With 180° Apart Ports Equivalent To OMS MS

About Hanjiu:

Hanjiu technology is the biggest hydraulic motors, orbit motors, low speed high torque motors, torquemotors manufacturer in China, we have the most completely range of them, matching Danfoss/ M+S/ Charlynn/ White/ Parker... with fast leading time, excellent price and best service. Our aim is to make your hydraulic system is easy and affordable!
